-6-
Tool Model Fastener Type
Fastener SKU Crown Width Gauge Length
BTFP72155
DA1520 N/A 15 1-1/4” (32mm)
DA1524 N/A 15 1-1/2” (38mm)
DA1532 N/A 15 2” (50mm)
DA1540 N/A 15 2-1/2” (63mm)
DA Type
Angled Finish
Nails
BTFP72156
FN1520 N/A 15 1-1/4” (32mm)
FN1524 N/A 15 1-1/2” (38mm)
FN1528 N/A 15 1-3/4” (45mm)
FN1532 N/A 15 2” (50mm)
FN1536 N/A 15 2-1/4” (57mm)
FN1540 N/A 15 2-1/2” (63mm)
Angled
Finish Nails
TOOL SPECIFICATIONS
All dimensions in inches unless otherwise specified.
BTFP72155
BTFP72156
Description
DA15 GA Angled Finish Nailer
FN15 GA Angled Finish Nailer
Engine Type
Oil-Free
Oil-Free
Operation Pressure Range
70-120 PSI (4.9 to 8.43kg/cm
2
) 70-120 PSI (4.9 to 8.43kg/cm
2
)
Maximum Operation Pressure
120 PSI (8.43 kg/cm
2
)
120 PSI (8.43 kg/cm
2
)
Fastener Type
DA15 Series
FN15 Series
Fastener Gauge
15 Gauge
15 Gauge
Fastener Range
1-1/4” - 2-1/2” (31mm - 63mm)
1-1/4” - 2-1/2” (31mm - 63mm)
Magazine Capacity
100
129
Length
12.8” (325mm)
14.3” (363mm)
Width
3.8” (97mm)
3.8” (97mm)
Height
12.1” (307mm)
12.1” (307mm)
Weight
4.26lbs (1.9kg) 4.53lbs (2.1kg)
Operating Pressure:
70 to 120 p.s.i.g. (4.9 to 8.43 kg/cm
2
). Select the operating pressure within in this range for best fastener
performance.
Air Consumption:
The BTFP72155 requires 1.8 cubic feet per minute or C.F.M. (51.0 liters per minute or LT/MIN) of free air
at 80 PSI (5.6 kg/cm2) to operate at a rate of 60 fasteners per minute. The BTFP72156 requires 1.9 cubic
feet per minute or C.F.M. (53.8 liters per minute or LT/MIN) of free air at 80 PSI (5.6 kg/cm2) to operate at a
rate of 60 fasteners per minute.
To determine the appropriately sized air compressor, take the actual rate at which the tool will be run and
compare the required C.F.M. (LT/MIN) to the compressors free air delivery (C.F.M./ LT/MIN) at 80 PSI
(5.6 kg/cm2).
For example, if your fastener usage averages 30 fasteners per minute, you need 50% of the tools
C.F.M. required to operate the tool at the rate of 60 fasteners per minute. In this case, be sure that your
air compressor can deliver a minimum of 0.9 C.F.M. (25.5 LT/MIN) at 80 PSI(5.6 kg/cm2) for optimum
performance of the BTFP72155.
FASTENER SPECIFICATIONS
* Stainless steel fasteners also available in certain sizes. Visit www.BOSTITCH.com for further details.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
