INTRODUCTION
T
he Bostitch D62ADC/DS-3219/DS-3522 series staplers are precision-built tools, designed for high speed,
high volume stapling. These tools will deliver efficient, dependable service when used correctly and with
c
are. As with any fine power tool, for best performance the manufacturer’s instructions must be followed.
Please study this manual before operating the tool and understand the safety warnings and cautions. The
i
nstructions on installation, operation and maintenance should be read carefully, and the manuals kept for
reference. NOTE: Additional safety measures may be required because of your particular application of the
tool. Contact your Bostitch representative or distributor with any questions concerning the tool and its use.
B
ostitch Fastening Systems, 701 E. Joppa Road, Towson, MD 21286.
INDEX
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Tool Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Air Supply: Fittings, Hoses, Filters, Air Consumption, Regulators,
Operating Pressure, Setting Correct Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Loading the D62ADC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Loading the DS-3219/DS-3522 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Tool Operation Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintaining the Pneumatic Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
NOTE:
Bostitch tools have been engineered to provide excellent customer satisfaction and are designed to achieve
maximum performance when used with precision Bostitch fasteners engineered to the same exacting
standards. Bostitch cannot assume responsibility for product performance if our tools are used with
fasteners or accessories not meeting the specific requirements established for genuine Bostitch nails,
staples and accessories.
LIMITED WARRANTY
Stanley Fastening Systems, L.P. (“Bostitch”) warrants to the original retail purchaser that this product is free
from defects in material and workmanship, and agrees to repair or replace, at Bostitch's option, any defective
product within 1 year from the date of purchase. This warranty is not transferable. It only covers damage
resulting from defects in material or workmanship, and it does not cover conditions or malfunctions resulting
from normal wear, neglect, abuse, accident or repairs attempted or made by other than our regional repair
center or authorized warranty service center. Driver blades, clinchers and o-rings are considered normally
wearing parts.
THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED TO THE DURATION OF THIS
WARRANTY. BOSTITCH SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.
This warranty is limited to sales in the United States and Canada. Some states do not allow limitations on
how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so
the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state.
To obtain warranty service, return the product at your expense together with proof of purchase to a Bostitch
Regional or authorized warranty repair center. You may call us at 1-800-556-6696 for the location of
authorized warranty service centers in your area.
