10
DIAL-A-DEPTH™ FASTENER CONTROL ADJUSTMENT
T
he DIAL-A-DEPTH™ Fastener control adjustment feature provides close
control of the fastener drive depth: from flush with the work surface to shallow
or deep countersink.
F
irst set the air pressure for consistent drive in the specific work as described
o
n page 4, then use the DIAL-A-DEPTH™ fastener control adjustment to give
the desired depth of drive.
IN ADDITION TO THE OTHER WARNINGS CONTAINED IN THIS
MANUAL OBSERVE THE FOLLOWING FOR SAFE OPERATION
• Use the BOSTITCH pneumatic tool only for the purpose for which it was designed.
• Never use this tool in a manner that could cause a fastener to be directed toward the user
or others in the work area.
• Do not use the tool as a hammer.
• Always carry the tool by the handle. Never carry the tool by the air hose.
• Do not alter or modify this tool from the original design or function without approval from
BOSTITCH, INC.
• Always be aware that misuse and improper handling of this tool can cause injury to
yourself and others.
• Never clamp or tape the trigger or contact trip in an actuated position.
• Never leave a tool unattended with the air hose attached.
• Do not operate this tool if it does not contain a legible WARNING LABEL.
• Do not continue to use a tool that leaks air or does not function properly. Notify your nearest
Bostitch representative if your tool continues to experience functional problems.
Dial-A-Depth
TM
Fastener Control Adjustment
TRIGGER LOCKOUT CONTROL
The trigger lockout control feature on BOSTITCH pneumatic tools provides
a trigger lock feature for added safety control. Push the lockout control
button in or out to activate or lock the tool trigger.
Trigger Lockout Control Button
