4. Construction and functional description
4.5 Vehicle Socket Connection Plan 13-pin 12 Volt
Fig. 10 135 338 74
Towing
vehicle
Towed
vehicle
Indicator
left
yellow
Indicator
left
Fog tail
lamp
blue
Fog tail
lamp
Mass for contacts
1
-
8
white
Mass for contacts
1
-
8
Indicator
right
green
Indicator
right
Tail light
right
brown
Tail light
right
Number plate
light
Brake light
right
Brake
lights
red
Brake light
left
Number plate
light
Tail light
left
black
Tail light
left
Reversing
light
grey
Reversing
light
Permanent positive 12
volt
Charging + for
battery
Not
assigned
Not
assigned
Mass for contacts 9
-
13
Socket
plug
13
-
pin DIN
72570
View of socket from
front
View of plug from
front
to

13 13-pin DIN 72570
