14. Oil temperature controller option
50
14.1 Safety regulations for the use
of an oil temperature
controller
Danger
Please observe the general safety
regulations in the compressor manual
when operating the compressor.
Operation of the oil temperature
controller is fully automatic.
Maloperation of the oil temperature
controller itself is impossible.
14.2 Design and function
See page 17, Fig. 8, for system function -
diagram.
With the aid of the oil temperature
controller, the compressor oil circuit is kept
at an optimum service temperature.
The oil temperature controller
regulations the temperature of the oil
within the set temperature limits, and only
feeds as much oil to the cooler as is
necessary to achieve the desired oil
temperature.
Fig. 48
14.3 Maintenance / care
This system is maintenance-free.
14.4 Troubleshooting
Compressed air temperature too low
Oil temperature controller in the oil line
is defective -> replace it.
Oil inlet
Oil outlet
