5 Installation 5
5.3 Floor Load 5.3
The place of installation must be designed according to the specified floor load.
This consists of:
Static load = machine weight + max. solvent filling and
Dynamic load = cage centrifugal force with normally distributed, spin-damp garments.
Do not forget to take into account the centrifugal forces that arise during the spin processes,
according to the local conditions (ground, supporting walls, etc.).
No resonance is permitted.
Please consult building specialists.
5.3.1 Dimensions
M21-M26-M30
M21 M26 M30
Depth*
mm
in
1060
41.7
1190
46.9
1295
51.9
Width*
mm
in
2200
86.6
2200
86.6
2200
86.6
Portion of the floor surface for force
transmission
m
2
ft
2
2.3
24.8
2.6
28.0
2.8
30.1
Weight without solvent
kg
lb
2120
4674
2270
5005
2390 5270
Weight with solvent (stat. load)
kg
lb
2500
5512
2700
5954
2800 6174
Cage centrifugal force (dyn. load)
N
lb
18100**
4070**
22400**
5040**
25900**
5820**
Floor load (stat. + dyn. load)
N/m
2
lb/ft
2
18500**
387
18800**
393*
19200**
400**
* Portion of the machine dimensions that is decisive for the size of the cage centrifugal force and
floor load.
** Calculated with:
- 21 kg (46.3 lb) or 26 kg (57.3 lb) or 30 kg (66.1 lb) load weight, with 50 % unevenly distributed
- Mixed outer clothing
- EBS
- 600 rpm
- Solvent weight 0.77 kg/dm
3
Building specialists will find the best solution, from both a structural and economic point of view,
for the design of the foundation, taking into consideration the system or machine-related
conditions and the local particulars.
Use a load dispatcher frame if the permissible load for your floor is not sufficient.
