BÖWE P25 - 5 Settings and Optimum Operating Values; Machine; Heating

13
5 Settings and Optimum Operating Values 5
Machine
Heating
P25
Steam
P30
Steam
Basic values:
Steam pressure (saturated steam) bar (psi) 4 - 5 (58.0 - 72.5) 4 - 5 (58.0 - 72.5)
Steam temperature (max. permitted) °C (°F) 150 (302) 150 (302)
Cooling water pressure bar (psi) 2 - 4 (29.0 - 58.0) 2 - 4 (29.0 - 58.0)
Low cooling water level switch bar (psi) 1 (14.5) 1 (14.5)
Cooling water temperature, max. °C (°F) 25 (77) 25 (77)
compressed air bar (psi) 6 (87) 6 (87)
Low air pressure switch (if present) bar (psi) 4 (58.0) 4 (58.0)
Cage speeds:
Cleaning /drying RPM 35 /33 35 /33
Spinning RPM 400 400
Reversing cycle (cleaning) sec. 10 /5 /10 10 /5 /10
Low level l (US gal) 60 (15.8) 75 (19.8)
High level l (US gal) 120 (31.7) 150 (39.6)
Pump pressure (max.) bar (psi) 2.5 (36.2) 2.5 (36.2)
Filter surface, economy filter m
2
(ft
2
) 5.0 (53.8) 5.0 (53.8)
Filter powder (only for machines without
emission-free still rake out system) kg (lb) 2.5 (5.5) 2.5 (5.5)
Tank I: Optimum filling volume (high level) l (US gal) 120 (31.7) 150 (39.6)
Detergent solution cooler:
Detergent solution thermal sensor:
Detergent solution cooler ON °C (°F) 15 - 30 (59 - 86) 15 - 30 (59 - 86)
Refrigeration technology:
Filling capacity, cooling agent R 404A kg (lb) 7.5 (16.5) 7.5 (16.5)
Expansion valve, Danfoss TES2
°C (°F)
°C (°F)
10 to minus 40
(50 to minus 40)
10 to minus 40
(50 to minus 40)
Nozzle size, reduction + solvent cooling No. 03 03
Drying No. 05 05
High pressure control ON bar (psi) 24 (348.1) 24 (348.1)
High pressure control OFF bar (psi) 28 (406.1) 28 (406.1)
Drying:
Cooling water regulator setting:
Adjust 4 – 6 min. after start of drying bar (psi) 22 (319.1) 22 (319.1)
Temp. sensor cage entry (water proofing
drying) °C (°F) 50 (122) 50 (122)
Temp. sensor cage exit °C (°F) 60 (140) 60 (140)
Temp. sensor after cooler:
Control value, drying °C (°F) 40 (104) 40 (104)
Control value, cycle end °C (°F) 15 (59) 15 (59)
Distillation:
Cooling water regulator condenser °C (°F) 45 (113) 45 (113)
Thermal sensor:
Cycle distillation OFF °C (°F) 135 (275) 135 (275)
Still stripping OFF °C (°F) 138 (280.4) 138 (280.4)
Thermal sensor, distilled solvent °C (°F) 55 (131) 55 (131)
Panel in steam feeder mm (in) 6 (0.24) 6 (0.24)
Panel in direct steam line mm (in) 4 (0.16) 4 (0.16)
P25/P30
