Assembly / Owner’s Manual
16
7. Insert Pivot Rod, Attach Interior Pivot Covers and Handlebar Arms, and Connect Cables
Be aware that the Handlebars are top heavy, and will want to pivot when attached onto the Pivot Rod. Be sure to stay out of the
path of the Handlebars and to gently allow it to pivot to a rest. Do not fully rotate the Handlebars or damage to the Cables will
occur.
Note: Do not crimp the Cables. Be sure to route the Cables through the additional opening of the Interior Pivot Covers. A decal has been
applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly.
Do not fully tighten hardware until cables have been connected.
I
X2
H
B
K
X2
12
4
21
G
G
X2
To Next Page
