Bowflex BXT6 - Page 65

65
23.Usinga6mmhexwrench,removethe2indicatedscrewsfromthe
Deck.
24. Lift and pivot the Front Roller out of the Frame, and slide it out of the
Walking Belt. This will free the Drive Belt from the Front Roller.
25.Usinga6mmhexwrench,nishremovingtheAdjustmentBoltfrom
the Rear Roller.
Note: Be sure to record the number of turns of the Adjustment Bolt it
takes to remove it. This will assist with reassembly.
Rear Roller
