Bowflex Conquest - Getting to Know Your Bowflex Conquest Home Gym

6
Base Crossbar
Step 1 Attach Stabilizers to Crossbar
Parts:
• Left and Right Stabilizers
• Base Crossbar
Tools:
• 7/32” Allen wrench
1-1 Insert Left and Right Stabilizers into
the Base Crossbar.
1-2 Install but do not tighten the hardware.
Assembling Your Bowflex Conquest
™
Home Gym
Step 2 Attach Squat Platform To Base Assembly
Parts:
• Base Assembly (from step 1)
• Squat Platform
Tools:
• 7/32” Allen Wrench
• 9/16” Wrench or Adjustable
2-1 Align the tabs on the Squat Platform
with the holes in the Base Assembly.
2-2 Install and completely tighten hardware
from steps 1 and 2.
Left Stabilizer
Right Stabilizer
3/8”x 3/4” Button
Head Screw
3/8”x 3/4” Button
Head Screw
3/8” Washer
Hardware (1:1):
6 Button Head Screw (3/8” X 3/4”)
6 Washer (3/8”)
2 Button Head Screw (3/8” X 3 1/4”)
4 Washer (3/8”)
2 Nylock Nut (3/8”)
Base Assembly
3/8”x 3 1/4” Button
Head Screw
3/8” Washer
3/8” Nylock Nut
Hardware (1:1):
Squat Platform
