7
Step 3 Attach Lower Tower to Base Assembly
Parts:
• Base Assembly (from step 2)
• Lower Tower
Tools:
• 7/32” Allen wrench
• 9/16” Wrench or Adjustable
3-1 Align the holes in the Lower Tower with
the holes in the Base Assembly.
3-2 Install and completely tighten the hardware.
Lower Tower
3/8”x 3/4” Button
Head Screw
Base Assembly
3/8”x 4” Button
Head Screw
3/8” Washer
Hardware (1:1):
6 Washer (3/8”)
2 Button Head Screw (3/8” X 3/4”)
2 Button Head Screw (3/8” X 4”)
2 Nylock Nut (3/8”)
Step 4 Attach Chest Bar to Lower Tower
Parts:
• Chest Bar
Tools:
• 7/32” Allen wrench
• 9/16” Wrench or Adjustable
4-1 With the pulleys pointing up, align the holes in the
Chest Bar with the holes in the Lower Tower.
4-2 Install and completely tighten the hardware.
Hardware (1:1):
4 Washer (3/8”)
2 Button Head Screw (3/8” X 5”)
2 Nylock Nut (3/8”)
3/8” Washer
3/8” x 5” Button
Head Screw
3/8” Nylock Nut
3/8” Nylock Nut
Assembling Your Bowflex Conquest
™
Home Gym
