12
Step 4 Tighten Tension Shaft Holder
Tools:
• 7/32” Allen Wrench
4-1 Use a 7/32” Allen Wrench to tighten the Tension Shaft Holder by
tightening the screws in numerical order shown on the tensioner.
Tighten the two screws marked 1, then the two marked 2, etc.
Note: Do not replace Top Cover at this time.
Tighten screws in order
1&1 , 2&2, 3&3, then
4&4.
Tension Shaft Holder
Tension screws
Assembling Your Bowfl ex Revolution
™
Home Gym
