Unboxing Your Bowfl ex Revolution
™
Home Gym
Warning: The Bowfl ex Revolution
™
Home Gym is very heavy. Whenever possible use
two people to unbox the main unit.
We have designed the packaging to make unboxing the main unit as safe and easy
as possible.
Step 1
1-1 Open the top fl aps of Box 2
(see Figure A) and split the
corners along the perforations
to expose the top layer of
styrofoam. (see Figure B)
Open top fl aps
Split box corners
along perforations
Top layer of
styrofoam
Step 2
2-1 Remove the Rear Stabilizer,
and Hardware Packs (see Figure C),
then remove the top layer of
styrofoam to expose the lower
portion of the Main Frame.
(see Figure D)
Figure A
Figure B
Figure C
Figure D
Rear Stabilizer
Hardware Packs
Top layer of
styrofoam
Lower portion of
Main Frame
W ARNING
A R N I N G
