10
Cable Routing and Storage
Squat Frame Pulley Cables
To install the Squat Frame Pulley cables, remove the ball end from the rope by pressing the insert out of the ball (Figure
A), and slide the ball off the rope. Route the cable under the pulley closest to the engine and reinstall the ball end
(Figure B).
When the Squat Pulley cables are not in use, store them by wrapping around the rope hooks as shown.
Figure A
Figure B
Cable
Pulley
Hooks
