Bowflex RevolutionXP - Leg Extension

13
Installing the Seat and Attachments
Leg Extension
The Leg Extension is used when doing leg extension and leg curl exercises. To attach the Leg Extension, pull down
on the pop-pin under the seat and insert the leg extension into the mounting bracket. Slide the Leg Extension to the
desired position and screw the pop-pin tightly into place. Then attach the hooks on the ends of the Squat Pulley
cables to the snaphook on the Leg Extension.
Leg Extension
Assembly
Seat
Pop-pin
