Bowflex SelectTech 2080 - Before Assembly; Parts; Basic Assembly Tips; Parts Identification

5
Maintenance Parts
6
7
10
10
11
8
8
9
9
5
14
4
13
12
3
14
15
1
11
5
5
2
8
Front
Back
Item Description Item Description
1 Base Tube, Front 10 Adjustment knob (selection knob)
2 Base Tube, Rear 11 Weight selection housing
3 Base Plates 12 Locking tab, plate
4 Levelers 13 Selection lip (pocket)
5 Base End Shrouds 14 Locking tab, base
6 Barbell Handle Assembly 15 Lock pin actuator, base
7 Curl Bar Handle Assembly
8 Adapter Plates
9 5-lb (2.27 kg) Weight Plates
