2
Owner’s Manual
Physical Dimensions
46 inches (117 cm)
Width 28.5 inches (72.5 cm)
Height 55.25 inches (140.5 cm)
Weight 185 pounds (84 kg)
Shipping Weight 220 pounds (100 kg)
System Capacities
Maximum Weight Capacity
300 lbs (136 kgs)
Speed
TC1000 0.5 to 3.8 MPH (0.8 to 6.1KPH )
TC3000 and TC5000 0.7 to 4.0 MPH (1.1 to 6.4 KPH)
1 to 12
See the Warranty section for full
information per machine type
Component Specifications
Belt
7.75 in x 38.5 in (19.5 cm x 98 cm)
Motor 0.5 hp continuous duty
Treadmill Incline 0% Grade
Frame Powder-coated steel
Operational Voltage 95 to 130 VAC 50 - 60 Hz
Operational Current 12A Max
A 14 gauge, 3 wire extension cord is permissible.
Regulatory Approvals Marks = c-ETL-US The standard for Safety
for Motor-Operated Massage and Exercise Machines, UL 1647, 3rd Ed. and Motor-
Operated Appliances, CAN/CSA-C22.2 No. 68-92
Patent Information
U.S. and International Patents Pending
Product Specifications
TC1000 TC3000 TC5000
