Bowflex Xceed Plus - Getting to Know Your Machine

6
Bowflex Xceed
™
Plus Assembly Manual
Qty:2
(5/16" x 2 1/2")
Qty: 2
(3/8" x 3")
Qty: 2
(3/8" x 1")
Qty: 4
(5/16" x 3/4")
Qty: 20
(3/8" x 3/4")
Qty: 2 Threaded Studs
(1/2" x 9 1/2")
Qty: 1
(3/8" x 5")
Qty: 4
(1/2")
Qty: 3
(3/8")
Qty: 2
Cap Screws (1/4
" x 1/2")
Qty: 3
Self Threading Screws (#10 x 1
")
Hardware Guide
Button Head Screws:
Flat Washers:
Qty: 28
(3/8")
Qty: 6
(5/16")
Qty: 3
(1/4")
Qty: 4
(1/2")
Nylock Nuts:
Tools you will need:
You will need the tools listed below to complete the assembly of your Bowflex Xceed
™
Plus
home gym. If you don’t have these tools, you can find them at any hardware or department
store.
(NOTE: Drawings not to scale.)
• Flat Blade Screw Driver
• Rubber Mallet
• Utility Knife
• Scissors
• Allen wrenches (included)
• 7/16" Combination Wrench
• 9/16" Combination Wrench
• Adjustable Wrench
• Socket Wrench Set
• Phillips Screw Driver
