50
23 BATTERY REPLACEMENT
When the indicator flashes on the display, it means
that there is around 1 month left to replace the bat-
teries (fig. 83). When the indication plus the
symbol appear on the display, the unit is no longer
operative and has set the heating and air-condition-
ing system to OFF (fig. 84).
ATTENTION. Failure to replace the batteries in time
may cause damage to the heating system (frost pro-
tection is not ensured).
To replace the batteries, proceed as follows:
23.1- Press button A on the base (fig. 85) and open
the unit.
Performing this operation when the battery low warn-
ing is flashing will cause all symbols on the display to
disappear but not be lost.
23.2- Insert three new alkaline LR03 size AAA 1.5V
batteries of the same type. Pay attention to polarity as
shown on the bottom of the housing (fig. 86).
