Bradley LD-3010 - Components; Components for Mounting Options

Installation LD-3010 Series
Bradley • 215-1219 Rev. Q: ECO 19-08-037B 2/27/2020 3
Components
Terreon OmniDeck
(shown with SL-TO1
oval integral bowl)
LD-3010-1
LD-3010-2
LD-3010-3
LD-3010-4
Components for Mounting Options
Contact your Bradley representative for Terreon lav deck and sink options.
Optional P-Trap
(S29-094)
Drain
Assembly
(269-1839)
for SL-
TO1 oval
undermount
only
Strainer
Rubber Washer
Fiber Washer
Nut
Right-Hand Mounting Bracket with
Mounting Strip (S45-2452RH)
Left-hand Mounting Bracket with
Mounting Strip (S45-2452LH)
PrePack, Access Panel
SL-TO1 (S45-2733)
PrePack, Access Panel, SL-TR1
(S45-2708)
Optional Waste Chute
(P10-696)
Carrier Sleeve, 18"
(266-049J)
Strainer and ADA
Offset Tailpiece
(269-1751)
for SL-TR1
rectangular
undermount only
Drain
Assembly
(269-1863)
for HS-Series
Only
Strainer
Rubber Washer
Mounting Ring
Lock Nut
Tailpiece Washer
Slip Nut
PrePack, Access Panel HS-Series
(S45-2820)
