Brady BBP12 User Manual

BPP12 User Manual
5
CHAPTER 1 Introduction
Product Introduction
Thank you for purchasing the BRADY BBP12 series bar code printer. Although the
printer is small, it delivers reliable, superior performance.
This printer provides both thermal transfer and direct thermal printing at user-selectable
speeds of 2.0, 3.0 or 4.0 ips. It accepts roll feed, die-cut, and fan-fold labels for both
thermal transfer and direct thermal printing. All common bar codes formats are available.
Fonts and bar codes can be printed in 4 directions, 8 different alphanumeric bitmap fonts
and built-in true type font capability. You will enjoy high throughput for printing labels with
this printer.
Compliance
FCC Class B,
CE Class B,
C-Tick Class B,
UL, cUL,
TÜ V/safety,
CCC,
EAC,
NOM
Note:
Continuous printing will cause printer motor overheat. Printer will stop printing
automatically about 10~15 minutes until motor is cooled down. Do not turn off
power when printer pauses or the data transfered to printer buffer will be lost.
Note:
The maximum printing ratio per dot line is 15% for this printer. To print the full
web black line, the maximum black line height is limited to 40 dots, which is
3.3 mm for 300 dpi resolution printer.

Brady BBP12 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	105.4 mm
Display	LCD
Color display	Yes
Product color	Black, Blue
Tape type	D2
Flash memory	128 MB
Internal memory	64 MB
Wi-Fi	-
Optional connectivity	Serial (RS-232), USB 2.0
Connectivity technology	Wired
Maximum label width	111.76 mm
Quantity per pack	- pc(s)
Cables included	USB
Operating temperature (T-T)	5 - 40 °C
AC input voltage	110 - 240 V

Weight and Dimensions

Depth	258 mm
Width	202 mm
Height	173 mm
Weight	2500 g
