5. Loading the Media
The MINIMARK printer can be operated in two different options:
Cutter On / Cutter Off.
- In cutter On mode, the printer automatically cuts the label after it
is printed ( 2 modes : cut between each label or cut at the end of
print job).
- In cutter Off mode, the printer will not cut any label.
The Cutter On/Off modes are set in the Printer Setup in Markware.
Loading the media (Continuous tape or Die-Cut labels)
1. Lift the top cover to expose the media compartment.
14
2. Remove the media hanger.
3. Load the media roll onto the hanger.
4. Unlatch the print head module.
Media Compartment
Media Hanger
Ribbon Roll
To Next Page
