Autonomous mode
14 DIGIMIC® wireless
Transmitting antenna
The powerful directed transmission antenna ensures the continuous control and audio downstream to each
single delegate unit within the system even over longer distances of up to 50m radius and beyond,
depending on the installation environment.
The antenna is removable for transport.
Adjustment of the transmitting antenna
The radiating side of the transmission antenna is the curved front side. This side must be adjusted toward
the room/microphone units.
To avoid interference it is not recommended to adjust the front side of the transmitting antenna
toward the receiving antennas.
antenna
front
antenna
back
Direction of signal radiation
Direction of signal radiation
Figure 4
Figure 5
