Technical Data
34 DIGIMIC® wireless
TMD/01 Conference Microphone
Description
The TMD/01 conference microphone is a professional electret microphone with ON status light ring indicator
and integrated wind shield. It has a matt black finish and is equipped with a rigid microphone neck with
gooseneck and a high quality connector (MINICON Neutrik). The TMD/01 is resistant to radio frequency
interference from mobile phones, PDAs and other wireless devices operated within a conference room.
Technical Data
Complies with international standard IEC914
Transducer Principle: Electret condenser
Directivity: cardioid
Frequency Response: 90 Hz ... 18,000 Hz see diagram
Sensivity
(free field, no load, 1 kHz): -43 dB (0dB = 1V/Pa)
Output Impedance: 1 kOhm
Max. SPL
(Signal pressure level): 120 dB
Signal-to-noise Ratio: >68 dB (A-weighted, 1 kHz)
Operating Voltage: 5 VDC (1.5V ... 9V)
Indicator ring: color red
Nominal current: 20 mA (50 mA max.)
Connector: Neutrik Minicon
Dimensions: Total length 310 mm, diameter 16.0 mm
Weight: 80 g
TMD/01 Conference Microphone -shock mount
The TMD/01 shock mount is the same like TMD/01 but with swinging suspended capsule to minimize
interferences from mechanical vibrations.
