Appendix
DIGIMIC® wireless 37
Appendix
Block diagrams
DIGIMIC wireless
Components:
DSpark Radio Transceiver unit
DChair Chairpersons´ Conference unit
DMic Delegates´ Conference unit with Microphone
DDoc Docking Unit with rechargeable battery
DTray Storage / Charging tray
TMD/01 Conference Microphone, electret
DPack Packing case space for one complete system with 10 DMic (DDoc, DSpark, DTray)
TMD/01
or
TM58/6
Connection to
external power
supply
Wireless Delegate Units
DMic with DDoc
DSpark
Radio Transceiver Unit
Connection to
LS signal OUT
Connection to
ext. signal IN
Wireless Chairpersons’ Unit
DChair with DDoc
Figure 13
