Appendix
38 DIGIMIC® wireless
DIGIMIC wired
TMD/01
or
TM58/6
Up to 100 wired units on 4 lines
D9 cable D9 cable
D9 cable
D9 cable
DSpark
Radio Transceiver
Unit
TMD/01
or
TM58/6
D9 cable
DCen
Central Control Unit
D9 cable
D9 cable
Input
External Audio and
Data
Output
PA System
Network
Media Control
SI System
Software
Delegates’ unit
DMic
Delegates’ unit
DMic
Chairpersons’ unit
DChair
Components:
DCen Central Control Unit
DChair Chairpersons’ Conference unit with Microphone
DMic Delegates’ Conference unit with Microphone
CChair Chairpersons’ Conference unit classic with Microphone
CMic Delegates’ Conference unit classic with Microphone
TMD/01 Conference Microphone, electret
D9 System cable
For detailed operating description of the Central Control unit DCen please refer to the manual
“DIGIMIC digital discussion system - wired”
