Page 9
Lift Terminology
Rear
Front
Outboard
(passenger's side)
Inboard
(driver's side)
“Arrows/30°-30°”6-13-90
(of vehicle)
(of vehicle)
Outboard
Right
Left
Inboard
Braun wheelchair lifts provide a method
of boarding and exiting applicable
motor vehicles. Braun wheelchair lifts
accommodate wheelchair passengers,
standees, and other mobility aid users.
The lift must be installed, operated,
and maintained as detailed in this
manual. Any use of equipment
other than instructed in this manual
is prohibited.
UP
DOWN
32819
FOLD
UNFOLD
32820
®
Pump
Module
Hand-Held
Pendant
Control
Top Parallel
Arm (2)
Adjustable Quiet-Ride Stow Block (2)
Vertical Arm Cover (4)
Roll Stop
Saddle (2)
Outer Fold Arm (2)
Pump Side Vertical Arm
Lift-Tite
Latch (2)
Roll Stop Latch
Platform Side Plate (2)
Inner Fold Arm (2)
Bottom Parallel
Arm (2)
Unfold Assist
Compression
Spring (2)
Main
Cylinder (2)
Tower (2)
E-Stop
Platform Light (2)
Opposite Pump
Side Vertical Arm
Switch Arm
Bridge Plate
Base
Plate
Base
Plate
Cover
Platform
Side Entry
Roll Stop
Outer Barrier Cylinder
(underside of platform)
Handrail
