Page 25
Lift Operating Instructions
Lift-mounted Control Switches: The
lift-mounted control switches activate lift
functions and optional power door operators.
The switches are function labeled. Press the
switches in the direction of the function label
to activate the intended lift function.
Switch Arm UP/DOWN Switch: A spring-
loaded sliding switch is built in the switch
arm. Slide the switch knob out to the UP
position to raise the platform. Slide the
knob in to the DOWN position to lower the
platform.
UP
DOWN
Discontinue lift use
immediately if any lift
component does not
operate properly.
Failure to do so may
result in serious
bodily injury and/or
property damage.
Platform
CLOSE
FOLD UP
Door(s)
Yellow
Orange
Red
OPEN UNFOLD
DOWN
Platform
Door(s)
Yellow
Orange Red
To Next Page
