Lift Operating Instructions
TO LOAD PASSENGER:
3. Unlock wheelchair brakes
and unload passenger from
platform.
Note: Roll stop must be fully
unfolded (ramp position) until
the entire wheelchair has
crossed the roll stop. See
Photos K and L.
I
J
K
L
2. Press red DOWN switch
until the entire platform
reaches ground level (stops)
and roll stop unfolds fully (see
Photos H and I). Release
switch.
Switch Arm Switch: Slide
knob in to DOWN
position.
See Photo G.
DOWN
G
H
1. Load passenger onto plat-
form facing outward and lock
wheelchair brakes.
Note: Roll stop must be fully
unfolded (ramp position) until
the entire wheelchair has
crossed the roll stop. See
Photos K and L.
M
N
To Next Page
