BraunAbility 02 Series - Inner Vertical Channel - Front

Page 23
Exploded Views and Parts Lists
Inner Vertical Channel - Front
NOTE: 2
NOTE:
3
NOTE:
6
NOTE:
5
NOTE:
6
NOTE:
8
6
17
19
2
30
29
2
18
27
27
16
20
18
2
2
14
15
7
12
10
11
28
8
19
21
22
13
5
1
20
20
23
24
8
NOTE: 1
NOTE:
7
NOTE:
3
9
4
3
PART NO.QTY.ITEM DESCRIPTION
13273
500-0110
9 14
10 4
RING-1/2 EXT SELF LOCK SNAP/AUTO-BK
PIN-ROLLER-TAPERED
25171
500-0133
84189
24012
500-0128
500-0175A
500-0104FWBM
PART NO.
3
8
2
8
11
QTY.ITEM
8
7
6
5
4
1
2
2
14
PIN-ROLLER-OUTER
DESCRIPTION
ROLLER-OUTER
WMT-INNER VERTICAL CHANNEL-FRONT
CYLINDER PIN
RING-RETAINING 5/8
BEARING-FLANGE-3/4" X 1/4"-12FDU04
BOLT-3/8-16 X 3/4" FLBHSCS-GD8
244404 SCREW-5/16-18 X 3/4" BHSC/AUTO-BK
402043KS
21708R021
21708R041
21759
34575
23173
1
1
1
2
2
4
CYLINDER ORIFICE FITTING KIT (2 FITTINGS)
CHAIN-LEAF-4x4-.5 PITCH x 21"
CHAIN-LEAF-4x4-.5 PITCH x 41"
PIN-COTTERED-4x4 LEAF CHAIN
PIN-COTTERED-466 CHAIN-LO PRO HEAD
PIN-COTTER 1/32 x 1/2 (4x4)
15
16
17
18
19
20
11092
26362
500-0064WBM
16114
10058
10068
2
2
1
1
1
1
CLIP-CABLE 3/8" PLASTIC
RIVET-SNAP-BLACK-0.201 x .256/.295
WMT-INNER VERTICAL CHANNEL
BUMPER-RUBBER 1"-5/16-18 x 5/8 STUD
NUT-5/16-18 HEX/AUTO-BK
WASHER-5/16" LOCK/AUTO-BK
21
22
23
24
25
26
10059BKWP2
NUT-3/8-16 HEX/AUTO-BK WITH PATCH27
500-21012
GUIDE-THREADED28
500-21752
GUIDE-OUTER29
262812
SCREW-5/16-18 X 1/2” BHSC-AUTO-BK30
500-3101A
13
12
11
6
ASSY-ROLLER
14
1515.6-0400AKS
ASSY-CYLINDER-15.625" STROKE / 23.250" RET. w/FITTINGS
1
500-00882 SPACER-RAISE/LOWER CYLINDER
500-01142 PIN-ROLLER-TAPERED-5/16-18
DWG. NOTES
1) PARTS 500-0128 AND 500-0175A TO BE LOCATED
TOWARD INSIDE OF CHANNEL (8X).
2) PARTS 500-0110 (4X) AND 500-3101A (6X) TO BE LOCATED
TOWARD OUTSIDE OF CHANNEL.
3) APPLY
" GREASE-MOBIL TEMP SCH 32 " (BA #28598)
TO INSIDE ROLLERS PRIOR TO ASSEMBLY (14X).
4) APPLY
" LOCTITE-BLUE/#242 GEN PURPOSE " (BA #18822) TO ALL
THREADED FASTENERS.
5) USE PINS 500-0114 WITH SCREWS 24440 (2X).
6) INSTALL ROLLER AND HARDWARE IN HOLE AS SHOWN.
7) PLACE PART 500-2101 TOWARD OUTSIDE OF CHANNEL IN THE
BOTTOM SET OF HOLES (2X).
8) PLACE PART 500-2175 TOWARD INSIDE OF CHANNEL ON THE
TOP SET OF HOLES (2X).
20
2
21
22
25
26
