BraunAbility 02 Series - Platform Sub-Assembly - Inner

Page 31
Exploded Views and Parts Lists
Platform Sub-Assembly - Inner
350311 GAS SPRING-14.47 EXT/9.02 COM-P1=1150N
PART NO.QTY.ITEM DESCRIPTION
34442A
500-0179FA
500-0179RA
18708
500-0155DS
34411-OBBM
34598
500-0180DS
3
2
1
1
1
1
1
16
1
1
1
8
7
6
5
4 SCREW-1/4-20 X 3/4"-FHSCS/AUTO BLACK
ASSY-SIDEPLATE w/TRACKS-REAR
ASSY-PLATFORM-CROSS BAR-NL500
27425MCI
1
9 HINGE-COVER-1.5" X 41.5"-SS
PULLEY-SPRING TENSIONER
BAR-INNER PLATFORM-NL500
PLATFORM-INNER DECK
ASSY-SIDEPLATE w/TRACKS-FRONT
PLATE-RAMP TRANSITION
PART NO.QTY.ITEM DESCRIPTION
1
14
34770
STRAP-PLATFORM TRANSITION HANDLE
115
500-0214A116 ASSY-BKT-MOUNT-IB LATCH
500-0189YT INBOARD BARRIER
35313117 PLATE-DECAL-ID NO. 7-STRAP-PLATFORM-NL500
11513
1
18
20
19
21
22
23
24
25
26
RIV-POP SD64BS-3/16"-.13/.25/AUTO-BK
1
3
500-0209BM
BRACKET-GAS SPRING MOUNT-PLATFORM
11387BK
3
5/16-18 NUT-AUTO BLACK
15858BK
BOLT-CARR 5/16-18 X 3/4/AUTO-BK
12611
1
BALL STUD-13MM,5/16-18 MALE (GAS SPRING)
10068
1
WASHER-5/16" LOCK/AUTO-BK
10058
1
NUT-5/16-18 HEX/AUTO-BK
500-0188BK
1
PLATE-GUIDE PATH-IB
12954
3
RIV-POP-SD43BS-1/8"-.13/.19/AUTO-BK
27
126082 CLIP-SAFETY (GAS SPRING)
28
500-0210BM1 BKT-PLATFORM HARNESS ATTACHMENT
29
149936 RIV-POP-SD66BS-3/16"-.25/.38/AUTO-BK
30
500-0212BM1 BKT-SPRING ATTACHMENT
31
85019-0002 FHSCS-1/4-20 X 1"
32
360841 BOOT-RIVET PROTECTOR
33
18619R029
82882
1
1
13
12
SCREW-5/16" X 3/8 SHLD SKT HD/SS
HINGE-S.S. 2" X 1/4" X 29"
30375
11513
14
17
11
10
SCREW-#10-32 X 1/2" BHSCS/AUTO BLACK
RIV-POP-SD64BS-3/16"-.13/.25"/AUTO-BK
DWG. NOTES
1) USE " LOCTITE-BLUE/GEN PURPOSE " (BA #18822) ON ALL THREADS
DURING ASSEMBLY.
2) APPLY
"GREASE-MOBILTEMP SHC 32" (BA #28598) TO PULLEY
INNER HOLE
AND INSERT INTO SLOT BEFORE BOLTING INTO PLACE.
3) PLACE HINGE 27425MCI ON TOP OF PLATE 500-0180DS.
NOTE: 2
20
4
30
32
15
16
10
30
25
24
6
9
17
14
18
33
10
1
3
7
13
8
27
28
28
11
11
2
21
12
22
23
5
29
19
31
4
26
34
34
2
38568BM
GUARD-HARNESS-PLATFORM
