BraunAbility 02 Series - Intermediate Vertical Channel (I-Beam) - Front

Page 25
Exploded Views and Parts Lists
Intermediate Vertical Channel (I-Beam) - Front
PART NO.QTY.ITEM DESCRIPTION
500-0111A
81039-000
500-2112
500-2100WBKN
3
2
2
1
11
4
1
BOLT-1/4-20 x 5/8" BHSCS ZINC
PIN-ROLLER-I BEAM
WMT-I BEAM-FRONT
ASSY-ROLLER-CHAIN-I BEAM
23173
21708R021
217596
1
5
1
7
1
CHAIN-LEAF-4x4-.5 PITCH x 21"
PIN-COTTERED-4x4 LEAF CHAIN
PIN-COTTER 1/32 x 1/2 (4x4)
DWG. NOTES
1) APPLY " GREASE-MOBIL TEMP SHC 32 " (BA #28598) TO
INSIDE ROLLER PRIOR TO ASSEMBLY.
2) APPLY
" LOCTITE-BLUE/#242 GEN PURPOSE " ( BA #18822)
TO THREADS.
500-2736BM8 1
GUARD-CHAIN ROLLER
5
NOTE: 1
NOTE:
2
2
3
8
4
1
7
6
