Page 24
Exploded Views and Parts Lists
Inner Vertical Channel - Rear
NOTE: 2
NOTE:
3
NOTE:
5
NOTE:
8
14
22
PART NO.ITEM DESCRIPTIONPART NO.QTY.ITEM DESCRIPTION QTY.
500-0110
500-3101A
17
16
11
10 4
6
PIN-ROLLER-TAPERED
ASSY-ROLLER
18
13273
25171
500-0133
84189
24012
500-0128
500-0175A
500-0104RWBM
3
8
2
8
11
9 14
8
7
6
5
4
1
2
2
14
PIN-ROLLER-OUTER
ROLLER-OUTER
WMT-INNER VERTICAL CHANNEL-REAR
RING-1/2 EXT SELF LOCK SNAP/AUTO-BK
CYLINDER PIN
RING-RETAINING 5/8
BEARING-FLANGE-3/4" X 1/4"-12FDU04
BOLT-3/8-16 X 3/4" FLBHSCS-GD8
244404 SCREW-5/16-18 X 3/4" BHCS/AUTO-BK
34737A HARNESS-STOW LEVEL w/SWITCH-NL5001
21708R0211 CHAIN-LEAF-4x4-.5 PITCH x 21"
231734 PIN-COTTER 1/32" x 1/2" (4x4)
19
21708R0411 CHAIN-LEAF-4x4-.5 PITCH x 41"20
345752 PIN-COTTERED-466 CHAIN-LO PRO HEAD21
217592 PIN-COTTERED-4x4 LEAF CHAIN22
161141 BUMPER-RUBBER 1" -5/16-18 x 5/8" STUD23
500-0064WBM1 WMT-INNER VERTICAL CHANNEL24
100581 NUT-5/16-18 HEX/AUTO-BK25
110922 CLIP-CABLE 3/8" PLASTIC26
263622 RIVET-SNAP-BLACK-0.201" x .256/.295"27
100681 WASHER-5/16" LOCK/AUTO-BK28
10059BKWP2 NUT-3/8-16 HEX/AUTO-BK-WITH PATCH29
500-21012 GUIDE-THREADED30
500-21752 GUIDE-OUTER31
262812 SCREW-5/16-18 X 1/2" BHSC-AUTO-BK32
500-01142 PIN-ROLLER-TAPERED-5/16-1812
1515.6-0400AKS1
CYLINDER KIT (2 CYLINDERS), 15.625" STROKE / 23.250" RET. w/FITTINGS
13
500-00882 SPACER-RAISE/LOWER CYLINDER14
402043KS1 CYINDER ORIFICE FITTING KIT (2 FITTINGS)15
303752 SCREW-#10-32 x 1/2" BHSCS/AUTO BLACK
DWG. NOTES
1) PARTS 500-0128 AND 500-0175A TO BE LOCATED
TOWARD INSIDE OF CHANNEL 8X.
2) PARTS 500-0110 (4X) AND 500-3101A (6X) TO BE LOCATED
TOWARD OUTSIDE OF CHANNEL.
3) APPLY
"
GREASE-MOBIL TEMP SCH 32
" (BA #28598)
TO INSIDE ROLLERS PRIOR TO ASSEMBLY (14X).
4) APPLY
"
LOCTITE-BLUE/#242 GEN PURPOSE
"
(BA #18822)
TO ALL THREADED FASTENERS.
5) USE PINS 500-0114 WITH SCREWS 24440 (2X).
6) INSTALL ROLLER AND HARDWARE IN HOLE AS SHOWN.
7) PLACE PART 500-2101 TOWARD OUTSIDE OF CHANNEL IN
THE BOTTOM SET OF HOLES (2X).
8) PLACE PART 500-2175 TOWARD INSIDE OF CHANNEL
IN THE TOP SET OF HOLES (2X).
NOTE: 1
NOTE:
7
NOTE:
3
NOTE: 6
6
2
20
26
3
8
2
4
17
15
25
27
28
16
7
13
30
5
1
32
29
8
24
2
26
9
22
18
31
21
10
11
12
18
29
18
27
18
23
19
21
11
