BraunAbility 02 Series - Platform Assembly

Page 30
Exploded Views and Parts Lists
Platform Assembly
500-2197A
11483
24998
34778A
25371
34357BM
500-0155A
PART NO.
3
4
2
2
1
1
QTY.ITEM
7
6
5
4
2
1
1
BOLT-1/4-20 X 3/4" BHSC/AUTO-BK
DESCRIPTION
STOP-SLIDING PLATFORM-NL500
ASSY-PLATFORM-INNER
SCREW-#4-40 X 3/4" RD. HD./AUTO-BK
303758 4 SCREW-#10-32 X 1/2", BHCS/AUTO-BK
PLATE-TAPPED #4-40 MICRO SWITCH
HARNESS-PLATFORM OCCUPIED
ASSY-PLATFORM-OUTER
DWG. NOTES
1) INSTALL PARTS 34357BM AND 25371 AFTER OUTER PLATFORM IS INSTALLED INTO PLACE.
2) LOCATE SPRING HOOK INTO SPRING ATTACHMENT BRACKET ON THE
BOTTOM SIDE OF THE PLATFORM INNER DECK.
3) USE (2) SCREWS FROM INNER
ASSEMBLY TO INSTALL GUARD INTO PLACE.
4) APPLY " LOCTITE-BLUE/#242 GEN PURPOSE " (BA #18822) TO THREADS.
1
500-0202
12954
500-0368BM
500-0369BM
34824
10095
34598
PART NO.
1
1
1
9
QTY.ITEM
15 2
1
1
SPRING-EXTENSION-1/2" X 8 3/4"-.05" WIRE
DESCRIPTION
COTTER PIN-1/8" X 1 1/2"/AUTO-BK
PULLEY-SPRING TENSIONER
RIV-POP-SD43BS-1/8"-.13/.19"/AUTO-BK
1834916 2
NUT-#10-32 w/LOCKWASHER/AUTO-BK
COVER-PLATFORM UNFOLD SWITCH
GUARD-PULLEY/SPRING
BRACKET-PULLEY SPRING TENSION
1
14
13
12
11
10
4
1
11
5
6
7
8
8
8
2
13
14
15
16
16
3
9
10
12
NOTE: 1
NOTE: 4
NOTE: 3
NOTE: 4
NOTE: 4
NOTE: 3
NOTE: 2
