BraunAbility 02 Series - Intermediate Vertical Channel (I-Beam) - Rear

Page 26
Exploded Views and Parts Lists
Intermediate Vertical Channel (I-Beam) - Rear
PART NO.QTY.ITEM DESCRIPTION
500-2112
28141
500-2014BM
500-2015BM
500-2100RWBKN
81039-000
500-0111A
3
1
2
2
11
7
6
5
4
2
1
1
1
WMT-I BEAM-REAR
BOLT-1/4-20 x 5/8" BHSCS-ZN
ASSY-ROLLER-CHAIN-I BEAM
SCREW-#8 x 3/8" BHCS-SS
CAM-INNER-MICRO SWITCH-FLR LVL
CAM-OUTER-MICRO SWITCH-FLR LVL / 1 " BELOW
21708R021
21759
23173
10
9
8
1
1
1
CHAIN-LEAF-4x4-.5 PITCH x 21"
500-273611 1
GUARD-CHAIN ROLLER
PIN-COTTERED-4x4 LEAF CHAIN
PIN-COTTER 1/32" x 1/2" (4x4)
PIN-ROLLER-I BEAM
DWG. NOTES
1) APPLY " GREASE-MOBIL TEMP SHC 32 " (BA #28598) TO
INSIDE ROLLER PRIOR TO ASSEMBLY.
2) USE "LOCTITE-BLUE/#242 GEN PURPOSE"
(BA #18822) ON THREADS.
NOTE: 1
NOTE:
2
NOTE: 2
1
2
11
3
4
5
7
6
9
10
8
