2.4.4 Drawing: Fuel Flow Sender Mounting
Fuel Flow
Sender
From
Tank
Fuel Filter
To engine
Min 60°
Optimal 90°
Fuel Flow Sender Mounted on Rotax 912 S as described in Section 5.3.6
