9 Information for certain Engines
9.1 Rotax 582
Connection on
engine
Sensor-Type BRÄUNIGER
Art. No.
Connection on
ALPHA
ALPHAALPHA
ALPHAMFD
Flag in Display
Exhaust Cyl 1 Typ K
M8x1 thread
F0307 EGT 1 EGT
Exhaust Cyl 2 Typ K
M8x1 thread
F0307 EGT 2 EGT
Watertemp Cyl
Head
Typ Pt100
1/8" NPT
F0308 WaterTemp (Pt)
Water/Oil
RPM Factor /6
9.2 Rotax 912 / 912S / 914
Connection on
engine
Sensor-Type BRÄUNIGER
Art. No.
Connection on
ALPHA
ALPHAALPHA
ALPHAMFD
Flag in Display
Exhaust Cyl 2 Typ K
M8x1 thread
F0307 EGT 1 EGT
Exhaust Cyl 3 Typ K
M8x1 thread
F0307 EGT 2 EGT
Watertemp/CHT
Cyl head 2
Typ K
M10x1,5 thread
F0305 CHT 1 CHT
Watertemp/CHT
Cyl head 3
Typ K
M10x1,5 thread
F0305 CHT 2 CHT
Oil temp Typ Pt100
M10X1,5 thread
F0315 OilTemp (Pt) Water/Oil Temp
Oil Press VDO analogue F0310 Oil Press Oil
RPM Factor *1
9.3 Rotax 503
Connection on
engine
Sensor-Type BRÄUNIGER
Art. No.
Connection on
ALPHA
ALPHAALPHA
ALPHAMFD
Flag in Display
Exhaust Cyl 1 Typ K
M8x1 Gewinde
F0307 EGT 1 EGT
Exhaust Cyl 2 Typ K
M8x1 Gewinde
F0307 EGT 2 EGT
Cylinder Head 1 Typ K
Sparkplug ring
14 mm
F0304 CHT 1 CHT
Cylinder Head 2 Typ K
Sparkplug ring
14 mm
F0304 CHT 2 CHT
RPM Factor /6
