39
11 Technical Data
Altimeter
Measuring Range: –500 to 9990 m (-1500 ft to 19999 ft)
Resolution: 1 m (3ft)
Sampling Rate: 1 samples / second
4 ½ digit digital display in meter or feet
VSI (Vario)
Measuring Range: +/- 10 m/s (+/- 2000 ft/min)
Resolution: 0,25 m/s (50 ft/min)
Sampling Rate: 5 samples / seconds
Hardware Time Constant: approx. 1.6 sec.
Display in m/s or ft/min depending on version
Fuel State
Bar graph with 10 bars
In 10% increments from 100% = full to 10% = reserve
User has to enter maximum fuel tank capacity (in litres or US-gallons)
Fuel Flow Meter from 5 to 49,9 litres/h, display in litres/h or US-gallons/h
Air Speed
ALPHA
ALPHAALPHA
ALPHAMFD Version A
Display Range: 40 – 220 km/h
Resolution: 2,5 km/h
ALPHA
ALPHAALPHA
ALPHAMFD Version B
Display Range: 60 – 340 km/h
Resolution 60 – 110 km/h: 2,5 km/h
Resolution 110 – 210 km/h: 5 km/h
Resolution 210 – 340 km/h: 10 km/h
ALPHA
ALPHAALPHA
ALPHAMFD Version C
Display Range: 24 – 130 kts
Resolution: 2 kts
Instrument also available in mph
ALPHA
ALPHAALPHA
ALPHAMFD Version D
Display Range: 32 – 190 kts
Resolution 32 – 70 kts: 2 kts
Resolution 70 – 120 kts : 2,5 kts
Resolution 120 – 190 kts : 5 kts
Instrument also available in mph
