Switching-off ports is done in SET-Modes 31 through 37.
SET Mode
Number
Temperature or fuel
Ports
Display Text Options
31 Pt100 WaterTemp Use Water Temp Port YES / NO
32 Pt 100 Oil temp Use Oil Temp Port YES / NO
33 EGT 1 Use EGT 1 Port YES / NO
34 EGT 2 Use EGT 2 Port YES / NO
35 CHT 1 Use CHT 1 Port YES / NO
36 CHT 2 Use CHT 2 Port YES / NO
37 Fuel flow Use Fuel Port YES / NO
Attention: Under set mode 37 it’s up from version 4.04 possible to
deactivate the fuel port. This may be helpful for trikes where the gas tank is
visible close to the pilot, or fuel systems with high flow back systems where
the flow sensor can’t work!
Note: The factory setting is all temperature ports ON!
WARNING: Make sure only unused temperature ports are switched
used temperature port with a connected sender is accidentally switched off,
the temperature is not displayed and also the alarm function is
inoperative!
