34 Technical Manual IQ-BASIC-GPS attachment
Bräuniger GmbH
12 Technical Data
Altimeter: max. 12’000 m - Scale 1m
Variometer: analog ± 10 m/s - Scale 0,2 m/s
digital ± 300 m/s . Scale 0,1 m/s
GPS: SiRF stare III receiver
Compass function, speed, position
Speed:
GPS from 1 km/h speed over ground
Wind wheel (optional) 0 up to 120 km/h
Waypoints: 200 WP
Routes: 1 Route with max. 40 WP
Max. storage time: 48 hours flight time at 10sec. recording interval
max. 291 hours at 60sec. recording interval
Memory:
Number of Tracklog-Points: 20’000
Number of flights: max. 50
Flight memory min / max values max. 50 flights
Dimensions: 138 x 74 x 23 mm
Weight: 178 grammes (batteries included, without holder)
Power supply: 2 x Alkaline batteries AA 1.5V, or 1,2V NiMH Accum.
Operation time: approx. 40 hours
Data storage and transmission according to IGC format
PC-connection: USB 1.1
Operating temperature: -15 °C to +50 °C
Holders for hang gliders and para gliders are available.
Technical data are subject to be altered without prior notification at anytime. Software upgrades
can be made via Internet by downloading the latest firmware version from our homepage
via user’s PC.
13 Approval / Conformity
Europe
Manufacturer: Brauniger GmbH/Flytec AG
Country of manufacture: Switzerland
Type: IQ-BASIC Marking:
The instrument was tested according to following Standards and is compliant to the required Standards.
ETSI EN 301 489-1 V1.6.1/ETSI EN 301 489-3 V1.4.1
IEC/EN 60950-1:2006: Safety Europe.
USA /Canada
according 47CFR15, ICES-003, Issue 4
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
