15
Doc. HD40-0007-02 En-Eu L-4
Battery Status Display
This icon is displayed when the optional PowerShell and Battery are connected. The level of
charge remaining on the Battery is indicated by the number of solid bars in the icon. The bars
ash when the Battery is charging. For example, the icon shown in Figure 9 indicates that the
Battery has between 25-50% of charge remaining. Make sure the Battery is fully charged before
each use.
Number of Solid Bars Charge Remaining
1 10-25%
2 25-50%
3 50-75%
4 75-100%
AC Power Indicator
This icon is displayed when the Z1 is connected to an AC power outlet via the Power Supply.
General Status Display
In standby mode, this display eld shows the current date. During treatment it shows the
currently selected Z-Breathe setting (1, 2 or 3).
FAULT
“FAULT” is displayed if one of several conditions has occurred that require your attention. See “Fault
Conditions” (page 21) for explanations of the FAULT codes.
REMINDER
“REMINDER” is displayed if there is excessive air leakage. See “Reminder Alert (Air Leak Detection)”
(page 21) for an explanations of REMINDER conditions.
