Trouble-shooting Guide
Problem
Possible Cause
Remedy
Excessive main
shear bolt breakage
Engaging PTO at high engine
speed or too quickly
• Idle tractor to engage PTO then bring up to full
operating speed
• Feather PTO lever into position
Excessive twine wrapped on
rotor causing flail movement
to be restricted
• Cut twine off rotor
Broken flails causing rotor to
be out of balance
• Replace broken flails (in pairs opposite each other)
Overloading rotor
• Set hoops to less aggressive position
• Slow rotation of bale
• Change direction of bale rotation
Incorrect shear bolt used
• Use correct shear bolt
Operating machine at less than
1000 PTO RPM
• Operate machine at rated 1000 PTO RPM
Excessive vibration
while processing
bales
Excessive twine wrapped on
rotor causing flail movement
to be restricted
• Cut twine off rotor
Broken flails causing rotor to
be out of balance
• Replace broken flails (in pairs opposite each other)
Overloading rotor
• Set hoops to less aggressive position
• Slow rotation of bale
• Change direction of bale rotation
Operating machine at less than
1000 PTO RPM
• Operate machine at rated 1000 PTO RPM
Rotor bearing failure
• Replace failed parts
Agitators stopping
Excessive loose material in
tub causing agitator to jam
• Reverse direction of bale rotation
• Turn bale more slowly
Tractor relief pressure set too
low
• Set tractor relief pressure to at least 2500 PSI
A single agitator
stopping
Mechanical flow divider valve
not functioning correctly
• Contact your dealer for repairs
Coupler between motor and
agitator broken
• Replace failed parts
No grain Flow
Flow control valve set too low
• Increase flow rate in tractor or on flow control valve
Flow Control Valve
going over relief
Flow control valve relief
pressure set too low
• Use hydraulic pressure gauge to ensure relief
pressure is set to 2200psi.
Auger chute at too shallow of
an angle for grain to clear fast
enough
• Run auger slower
• Run chute at steeper angle
3 Bale Kit not
clamping at full
pressure
Second bale is being lifted too
high before clamping
• Lower fork height to horizontal before clamping
bale
Lockout mechanism is set too
early
• Adjust lockout mechanism to stop clamp at higher
fork position
With 3 Bale Kit,
fork is not lifting to
full stroke
3 Bale Kit is slightly closed
• Lower fork and open 3 Bale Kit fully before lifting
