Bridgeview BALE KING 5300 - Page 58

Bridgeview Manufacturing Inc.
Page 54
Deflector & Hose Cover - S/N BK7168 & Down
#
DESCRIPTION
PART #
QTY
1
Bolt, 3/8" x 1"
13806
8
2
Deflector Rubber Channel
22423
1
3
Deflector Rubber
10477
1
4
Nut, 3/8" Nylon Lock
10806
8
5
Carriage Bolt, 3/8" x 3/4"
14072
14
6
Deflector Flipper Pin
24464
1
7
Nut, 3/8" Serrated Flange
10271
18
8
Compression Spring
24461
1
9
Roll Pin, 3/16" x 1-1/4"
10302
1
10
Deflector Pivot
22426
2
11
Inner Deflector
31749
1
12
Bolt, 3/8" x 3/4"
11816
4
13
Hose Cover
22436
1
14
Cylinder Pin, 3/4" x 3" Usable
22007
1
15
Cotter Pin, 3/16" x 1-1/4"
11669
4
16
Hydraulic Cylinder, 1-1/2" x 6" x 3/4"
* Seal Kit
21711
23738
1
17
Cylinder Pin, 3/4" x 3" Usable
22007
1
18
Deflector Rubber Flipper
24463
1
19
Outer Deflector
31754
1
20
Nut, 1/2" Serrated Flange
10273
12
21
Bolt, 1/2" x 1"
10824
8
22
Bolt, 1/2" x 2"
10322
1
23
Deflector Lock
22422
1
24
Pin Stud
13231
1
25
Lynch Pin
13233
1
26
Hose Cover Front
22945
1
27
Flat Washer, 3/8"
11667
10
