Bridgeview Manufacturing Inc.
Three Bale Kit Left Arm (Series 1)
Nut, 5/16” Serrated Flange
Bolt, 5/16” x 3/4” Carriage
Nut, 1/2” Stover Lock Fine Thread
Lockout Mechanism – SEE DETAIL
Bolt, 1/2” x 1-3/4” Fine Thread Gr. 8
NOTE: If your machine only has accommodation for 4 bolts instead of
6, the holes should be drilled out to 5/8” and a 5/8” x 1-3/4” UNF Gr.8
Bolt should be installed.
Bolt, 1/2” x 1-1/4” Fine Thread Gr. 8
Bolt, Shoulder 1/2” x 2-1/4” x 3/8”
To Next Page
