Three Bale Kit Lockout Mechanism (Series 1)
#
DESCRIPTION
PART #
QTY
1
3 Bale Kit Rocker
31934
1
2
Bolt, Shoulder 1/2” x 2-1/4” x 3/8”
31358
1
3
3 Bale Kit Spring Guide Rotator
31920
1
4
3 Bale Kit Upper Spring Guide
31915
1
5
Spring
19471
1
6
Bolt, 3/8” x 1”
13806
2
7
3 Bale Kit Lower Spring Guide
31911
1
8
3 Bale Kit Left Mount
31898
1
9
Cotter Pin
21169
1
10
3 Bale Kit Plunger
31925
1
11
Nut, 3/8” Serrated Flange
10271
2
12
3 Bale Kit Valve
30980
2
13
Nut, 5/16” Serrated Flange
11814
2
14
Nut, 3/8” Nylock
10806
1
15
Nut, 1/2” Fine Thread
32167
1
16
Clevis Pin, 1/2” x 6”
31835
1
17
Bolt, 5/16” x 3-1/2”
30914
1
18
Lynch Pin
13233
1
19
Lockout Door
31928
1
20
Nut, 5/16” Nylock
11815
1
21
Bolt, 5/16” x 4 1/2”
21836
2
