Bridgeview BALE KING 5300 - Page 78

Bridgeview Manufacturing Inc.
Page 74
Three Bale Kit (Series 2)
#
DESCRIPTION
PART #
QTY
1
Left Arm
33328
1
2
Right Arm
33329
1
3
Torsion Bar
33330
1
4
Torsion Bar Mount
33331
2
5
Rear Support Left
33332
1
6
Rear Support Right
33333
1
7
Cylinder Base Mount
33334
1
8
Cylinder Mount Tub Adaptor
33387
1
9
Timing Bar
33335
2
10
Shaft Rear Bushing
33336
2
11
Torsion Clamp
33337
2
12
Hydraulic Cylinder, 2-1/2” x 8” [comes with pins 15]
* Seal kit
30126
17609
1
13
Depth Control Valve
30980
1
14
Press-in Bushing, 1”
23708
2
15
Cylinder Pin, 1 x 3-1/8”
10339
2
16
Cotter Pin, 3/16 x 1-1/2”
10072
4
17
Grease Zerk, 1/4”
16364
4
18
Bushing, 1” OD x 3/4” ID x 1-1/16”
29063
2
19
Rubber Torsion Bar
33356
8
20
Bolt, 3/4 x 3”
27451
2
21
Nut, 3/4” Stover Lock
11823
2
22
Bolt, 1/2 x 1-3/4” Fine Thread
32151
15
23
Nut, 1/2” Stover Lock Fine Thread
32153
15
24
Bolt, 1/2 x 3-1/2”
10353
2
25
Bolt, 1/2 x 1-1/4”
10240
9
26
Nut, 1/2” Stover Lock
20154
10
27
Bolt, 3/8 x 1-1/4”
10253
12
28
Nut, 3/8” Nylon Lock
10806
12
29
Bolt, 5/16 x 2-1/2”
19115
2
30
Nut, 5/16” Nylon Lock
11815
2
