Bridgeview BALE KING 5300 - Page 85

Bridgeview Manufacturing Inc.
Page 81
Total Ration Cross Auger
#
DESCRIPTION
PART #
QTY
1
Cross Auger Pipe
30179
1
2
Cross Auger Half Clamp
30401
1
3
Bolt, 3/8” x 1”
13806
4
4
Nut, 3/8” Stover Lock
17586
5
5
Bolt, 5/16” x 1.75”
21726
1
6
Hydraulic Hose Clamp Cap, Large
21715
1
7
Hydraulic Hose Clamp, 1/2”
21561
2
8
Bolt, 1/2” x 1-1/2”
10174
5
9
Cross Auger Top Clamp
30187
1
10
Nut, 1/2” Serrated Flange
10278
8
11
Spout Strap *Includes both parts*
25122
1
12
Nut, 1/4”
20891
2
13
Washer, 1/4” Flat
14448
2
14
Bolt, 1/4” x 3/4” Truss Head
17638
2
15
Cross Auger
30169
1
16
Cross Auger Motor Mount
30194
1
17
Bolt, 1/2” x 1-1/4”
10240
4
18
Cross Auger Motor, WS080
30132
1
19
Nut, 1/2” Stover Lock
14393
6
20
Lock Pin, 1/4” x 1.25”
13951
1
21
Chain, 3/16” x 20 links
25121
1
22
Bolt, 3/8” x 2”
10279
1
23
Auger Spout
10543
1
24
Nut, 5/16” Nylon lock
11815
1
25
Nut, 5/16” Serrated Flange
11814
1
26
Bolt, 5/16” x 1-1/4”
24418
1
27
Cross Auger Bottom Clamp
30189
1
