4.9 Recommended Fuse Values
Supply
Voltage
Network Size
(Number of
Sensors)
Power
Consumption
Steady
State
Current
Inrush
Current
Recommended
Fuse Value
12VDC
1 3.6W 0.31A
<0.85A,
<20mSec
1A
2 7.2W 0.62A
3 10.8W 0.93A 2A
4 14.4W 1.24A
5 18W 1.55A
6 21.6W 1.86A 3A
7 25.2W 2.17A
8 28.8W 2.48A
24VDC
1 4.1W 0.17A <0.45A,
<20mSec
1A
2 8.2W 0.34A
3 12.3W 0.51A
4 16.4W 0.68A
5 20.5W 0.85A 2A
6 24.6W 1.02A
7 28.7W 1.19
8 32.8W 1.36
