Brigade Backsense BS-9000 - Electrical Specification and Approvals

35
Electrical Specification
Input
V
oltage
Range
9
to
3
2 Vdc
Input
C
urrent
(per sensor)
typ.
0.
31
A
a
t
12V
dc / typ.
0.17A
at 24Vdc
Power Supply Fusing Dependent upon number of sensors in network. See section
4.9
for details
Vehicle
C
onnection
s
System supply positive
&
negative
.
Host Connections
CAN High & CAN Low
Voltage
P
rotection
ISO
16750
(
o
ver
and reverse
voltage protect
ion
)
Approvals
CE
ECE Regulation No. 10 Revision 4 (“E-marking”)
ISO 16750
ISO 13766
EN 13309
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Any change or modifications not expressly approved by the responsible party responsible for compliance could void the user’s
authority to operate the equipment.
EU Declaration of Conformity
Product Types:
Brigade Backsense Radar Obstacle Detection System BS-9000
Manufacturer:
Brigade House, The Mills, Station Road, South Darenth, DA4 9BD, UK
This declaration of conformity is issued under the sole responsibility of Brigade Electronics.
Objects of the declaration:
Radar sensor, cables and termination
The objects of the declaration described above are in conformity with the relevant Union harmonisation legislation:
Directive 2014/53/EU
Relevant Harmonised Standards:
• EN301489-1 V2.1.1(2017-02) and EN301489-3 V2.1.0 (2017-03)
• EN300440-2 V1.4.1(2010-08) and EN300440-1 V2.1.1(2017-03)
Additional information:
• Operational Frequency Band: 24050MHz – 24250MHz
• Maximum Transmitted Power: 19.20 dBm
• This equipment should be installed and operated with a minimum distance of 20cm between the radar sensor and
any human body.
Signed for and on behalf of Brigade Electronics Group PLC
11/01/2018, South Darenth, DA4 9BD, UK
David Wallin, Quality and Standards Manager
Brigade Electronics
BS-XXXX
