6.7SUPPLEMENTARY EXPLAINATION:
Once switching on, you will see standard dynamic
balance mode setup by the computer. When selecting
ALU mode and the configuration of the aluminum alloy
rim is similar to the above standard ALU1\ALU2\ALU3,
you can get relative accurate balance effect. If the
section of the tire similar to the one given be the
program, you need do some adjustment on the position
and weight of the weight. General speaking, 1~2 times
of adjustment can reach relative satisfactory balance
effect.
7 PROGRAM SETUP
7.1 PROGRAM FUNCTION INTRODUCTION
Press program key to enter the program setup
menu.
7．1.1 [SET] –[OPT]-[ ] (unbalance value optimum
calibration)：Press key to confirm the entrance.
Select up and down key to adjust the
unbalance threshed value. You can choose from
15Gr-100Gr and press key to confirm when you
choose the corresponding value.. Press key to
enter the next function setup level.
7.1.2 [SET] –[p]-[ ] (protective hood setup) Once
again press to confirm the entrance. Select
up/down key to ON/OFF setup the protective
hood function and ten press key to return.
7.1.3 [SET]-[SP]-[ ] （ protective hood control ）
Select to enter and then press key
To confirm the entrance and the setup is similar to the
above.
7.1.4 [SET]-[APP]-[ ]-( light tire minimum
unbalance setup) You can setup 1Gr and 5Gr. The
setup is similar to the above.
7.1.5
7.1.6 [SET]-[BIP]-[ ] (beeper setup) You can setup
the on/off of the beeper.
7.1.7 [SET]-[Rl1]-[ ] (set up if the automatic scale
Dis -to the machine- input automatic or not) You can
choose on or off.
7.1.8 [SET]-[Rl2]-[ ] (set up if the automatic rim
breadth input automatic or not) You can choose on
or off.
7.1.9
7.1.10 [SET]-[PRN]-[ ] ( printer setup switch) You
can select on/off. If select on , you can select printing
When press key to print the balance result.
7.1.11 [SET]- [UP]-[ ] ( enter the next menu of the
programm) Involve the test on the various sensors
and scales and the self-calibration.
7.1.12 [SET]- [UP] Press key to enter into the
special function setup.
[TES] –[INT]- (sensor\scale measurement) It can
separately measure the photocell sensor, piezoelectric
sensor, Dis, Bre and Dis . Through the test, we can
identify the problem.
Press key to enter and the display will display
TES POS (phase sensor). Rotate the tire forward and
backward and the display will display [TES] –[POS]-
[XXX]. If rotate the tire backward, the value of[ XXX] will
increase and if forward, [XXX ]will decrease.
Once again press key to enter [TES]- [STA]
(dynamic test sensor). When service, press the
sensor vertical to the main shaft.
